P-LED
Pushbutton dimmer for LEDs adjustable at the beginning of phase (TRIAC)
LED compatible push button regulatorAdjustable to Phase Principle (PF) (TRIAC). Regulation range from 5% to 95%, equivalent to the same percentage of energy savings.Last power up memory. Function ofOn from minimum holding down with light off.
REGULATION AT THE BEGINNING OF PHASE (TRIAC)
Installation scheme
4-wire installation. Connect Neutral to terminal 1 and Phase to terminal 2. In terminal 3 connect the load return, which comes from Neutral. Finally, at terminal 4, connect the turn of the button / es that comes from the Phase. Up to 5 push buttons can be connected in parallel with light indicator and unlimited without it.
Download the product data sheet
For more details of characteristics, operation, control, installation diagram, admissible loads, maximum admissible power, etc. You can view and download the product data sheet by clicking on the button below.
Multimedia
The video shows an example of assembly in a conventional installation, carried out by one of our technicians. Likewise, the basic operation of the product is shown.
Regulation to TRIAC
Dimming at the beginning of phase through TRIAC, which makes it compatible with most standard LED lamps, halogen and incandescence.
Functioning
With a short press you turn the light on or off progressively.
Holding down the regulation takes place, stopping when releasing the button.
Up to 500W of load
It admits up to a maximum of 300W of maximum load for dimmable LEDs at the BEGINNING OF PHASE and 500W for halogens and incandescence.
