Multi Dimmer 250
UNIVERSAL push button dimmer for any dimmable LED
UNIVERSAL push button dimmer with memory that varies the luminosity and the electrical consumption. Regulation range from 1% to 100%, equivalent to the same percentage of energy savings. It has memory of last dimming level even after power failure, and turn-on from minimum function by keeping pressed push button with light off. Minimum level adjustment that ensures maximum compatibility with any dimmable LED lamp. It stops to the maximum and minimum when you are dimming.
100% COMPATIBLE WITH ANY DIMMABLE LED (230VAC ~ 50Hz)
Installation scheme
4-wire installation. Connect Neutral to terminal 1 and Phase to terminal 2. In terminal 3 connect the load return, which comes from Neutral. Finally, at terminal 4, connect the turn of push button/s that comes from the Phase. Up to 5 push buttons can be connected in parallel with light indicator and unlimited without it.
Download the product data sheet
For more details of characteristics, operation, control, installation diagram, admissible loads, maximum admissible power, etc., you can view and download the product data sheet by clicking on the button below.
Maximum compatibility with LEDs
Thanks to its innovative design and technology, it is 100% compatible with any dimmable LED (230VAC).
Minimum level adjustment
With the manual adjustment potentiometer, you can select the lowest level of regulation that, depending on the type of lamp, must be higher or lower. This prevents the lamp from turning off completely or from lighting up too much when it is dimmed to a minimum.
Up to 250W load
Supports up to 250W (PF=1) of maximum load for LEDs, halogens and incandescence.(IMPORTANT: 250W for LEDs with power factor = 1. If, for example, the PF = 0.5, the maximum power will be 125W). If you need to regulate a higher load, click here.
