Dimmer LED
Regulator with pushbuttons for LEDs adjustable at the end of the phase
Push-button regulator with memory that varies brightness and power consumption. Regulation range from 5% to 95%, equivalent to the same percentage of energy savings. Last power-up memory even after power failure. Minimum power-on function by holding down with light off. Installation without NEUTRAL.
COMPATIBLE WITH ADJUSTABLE LEDs AT THE END OF THE PHASE
Installation scheme
Installation without 3-wire NEUTRAL. Connect Phase to terminal 1. At terminal 2 connect the load turn, which comes from Neutral. Finally at terminal 3 connect the turn of the push-button / s that comes from the Phase. Up to 5 push buttons can be connected in parallel with light indicator and unlimited without it.
Download the product data sheet
For more details of characteristics, operation, control, installation diagram, admissible loads, maximum admissible power, etc. You can view and download the product data sheet by clicking on the button below.
Multimedia
The video shows an example of assembly in a conventional installation, carried out by one of our technicians. Likewise, the basic operation of the product is shown.
Installation without NEUTRAL
Thanks to its technology, it allows installation with only 3 wires, without having to lower the Neutral into the mechanism box.
Functioning
With a short press you turn the light on or off progressively. Holding downregulation occurs, stopping when the button is released.
Up to 300W load
It admits from 5W to a maximum of 300W of maximum load for adjustable LEDs at the END OF PHASE, halogens and incandescence.
